10/16A V2L EV Charging Cable + 2-Bit Strip

The discharge gun product provided by AUPINS is equipped with a 10A+16A combination jack, which is convenient and flexible to use and can be used with general household appliances and high-power electrical equipment.


DATASHEET

Datasheet of 10/16A V2L Charging Cable + 2-Bit Strip

Specifications of 10/16A Discharge Gun +2-bit strip

Mechanical Performance

Mated force

<100N

Mated cycles

copper

Cable standard

GB/T 33594-2017

Outer sheath material

black, rubber

Environment Performance

Operating temperature

-40℃ ~ +85℃

Protection degree

IP55

Flame class

UL94-V0

Electrical performance

Rated voltage

250V /440V AC

Rated current

10A/16A

Insulation resistance

≥100MΩ

Withstand voltage

2000V AC

Wire harness specification

1.5mm²/2.5mm²

Cable outer diameter

12.5±0.5/15.5±0.5
