Automotive Wiring Harness Assembly Process and Requirements

Table of Content [Hide]

    Automotive Wiring Harness Assembly


    Because the wiring position of the assembly line is complex, continuity testing has become an indispensable step. The fixture can only be tested after being confirmed by PE and QE. QE needs to simulate possible defects, and the operator needs to perform a good and bad product inspection before each continuity test. After confirmation, mass production can be carried out.


    Finished product inspection is the final confirmation before product packaging and shipment. Check whether the terminals and CONNs are within tolerance. Check whether the wire binding loop is uniform. Check whether the assembly method of the components is correct.


    Automotive Wiring Harness Assembly Process Requirements



    After the automotive wiring harness and wiring harness connector pins, including those used with different types of charger pins or a wire for electric car charger, are assembled into finished products, the continuity rate of the wiring harness must be tested, and the continuity rate must reach 100% without short circuits, open circuits, or wrong paths. At the same time, it must meet the quality standards required by customers of the automotive wiring harness, and provide a safety quality guarantee certificate during packaging. Every step of the automotive wiring harness assembly inspection process strives to be meticulous and strives for excellence, and follows the ISO 9001:2000 quality management system to standardize the operation requirements.


    The work instruction is a specific work activity program developed to ensure the quality and safety of the process. The benefit is to make the work process more clear and reduce the errors caused by differences in operators, improve the consistency and stability of the product, reduce product quality accidents, facilitate future work improvement and quality management, and also include requirements for work, product acceptance, and judgment criteria.
