Conform to the provisions and requirements of IEC62196-3-2022.
Using riveting pressure process with none screw,have a beautiful apprearance.Hand - held designconform to the ergonomic principle, easy plug.XLPO for cable insulation prolonging the aging resis-tance life span, TPU shenth improved the bendinglife and wear.Excellent protection performance,protection gradeachiev-ed IP55( working condition).
OEM/ODM services available
We can customize cable length, color, and redesign according to customer requirements.
Ergonomic handheld design for comfortable grip. Reliable plug-and-play design, compact structure, and easy installation.
Excellent environmental adaptability. Wide temperature range design from -20℃ to 45℃, easily handling various climates.
Specifications of GB/T DC Charging Connector | |
Mechanical Performance | |
Insertion Force | <100N |
Mated cycles | No-load Plug>10000 times |
Certificate | TUV,CE, RoHS |
Environment Performance | |
Operate Temperature | -30°C-+50°C |
Protection degree | IP55 IK08 |
Flame class | UL94-V0 |
Impact of External Force | 1m Drop and 2t Vehicle Run Over |
Electrical performance | |
voltage | 1000V DC |
current | 80A/125A/150A/200A/250A/300A |
Insulation resistance | >1000M2(DC500V) |
Pins Temperature Rise | <50K |
Withstand Voltage | 2500V |
Contact Impedance | 0.5 MO MAX |
