NACS Vehicle Plug

The NACS Vehicle Plug developed by AUPINS has an ergonomic handle design that is comfortable to hold and easy to plug and unplug. The locking bayonet anti-loosening device ensures a stable and reliable connection. It pays great attention to user experience and is easy to operate. At the same time, it has built-in multiple safety protection mechanisms to ensure a safe and worry-free charging process. AUPINS is committed to providing users with more convenient and fast charging solutions through continuous innovation.


Get a Quote

Features of NACS Vehicle Plug

  • All parts must be complant RoHS

  • Reliable plug-in and pull-out

  • Compact structure, easy installation

  • Good environmental resistance


Specifications of NACS Vehicle Plug

NACS Vehicle Plug/ Socket

Code

Type

Rated current

Rated voltage

Test voltage

13001

AP-NACS-Plug

65A/60A/50A/48A/40A/32A/16A

500VDC/240VAC

2KV(50Hz/1min)

13002

AP-NACS-CS

350A/300A/250A/200A/150A/125A/80A/65A/60A/50A/48A/40A/32A/16A

1000VDC

3KV(50Hz/1min)


Applications of NACS Vehicle Plug

1. Mechanical properties:

unmated: IP2X

Connector System: ￠9mm

Safety class: Ⅱ

Insertion/withdrawal force: <90N

Locking system: Snap-in

Degree of protection, mated: Type 3R

Durability: 10000 Mating Cycles


2. Environmental performance:

Waterproof Level: IP67

Insulation material: PC

Flame class: UL94-VO

Ambient temperature range: -40℃..+50℃

Operating temperature: -40℃-105℃

Salt mist spray test. degree of severity 5: IEC 60068-2-52

Contact material: Copper Alloy, Silver plated


3. Electrical performance:

Rated voltage: 500VDC/240VAC

Rated current: 65A/60A/50A/48A/40A/32A/16A

Test voltage: 2KV(50Hz/1min)

Contact resistance of plug connectors: 0.35mΩ Max
